VL12004

Description

Small Footprint Class A/B Amplifier
Utilizes Class A/B Technology
Full Range Class A/B
Low Level Inputs
80% more efficient than tradtiional Class A/B amplifiers

Peak Power: 1200W
Power RMS 2Ω @ 14.4V: 4 x 150 Watts
Power RMS 4Ω @ 14.4V: 4 x 75 Watts
THD+N @ Nominal Power: 4×75 Watts 4Ω
Frequency Response: 10Hz ~ 30kHz
SNR: 93dB
Input Sensitivity: 0.2V to 6V
Damping Factor: 100
Operating Voltage: 9V to 16V
High Pass Filter: 50Hz to 250Hz
Low Pass Filter: 50Hz to 250Hz
Total Efficiency: 70%
Max Current Draw (A): 53
Music Current Draw (A): 28
Dimensions: 5.8” W x 11.4” L x 1.9” H
