VL1000D

Description

Small Footprint Class D Amplifier
Utilizes Class D Technology
0-12dB Variable Bass Boost
Includes Sub Level Remote
80% more efficient than tradtiional Class A/B amplifiers

Peak Power: 1000W
Power RMS 1Ω @ 14.4V: 1 x 250 Watts
Power RMS 2Ω @ 14.4V: 1 x 125 Watts
Power RMS 4Ω @ 14.4V: 1 x 62.5 Watts
THD+N @ Nominal Power: 1 x 250 Watts 1Ω
Frequency Response: 15Hz ~ 250Hz
SNR: 90dB
Input Sensitivity: 0.2V to 9V
Damping Factor: 150
Operating Voltage: 9V to 16V
High Pass Filter: 10Hz to 50Hz
Low Pass Filter: 50Hz to 220Hz
Total Efficiency: 250W
Max Current Draw (A): 30
Music Current Draw (A): 16
Fuse Recommendation: 20A
Dimensions: 5.8” W x 7.75” L x 1.9” H
